Sanden 95943 Ford / Sterling F1HZ-19703E

Ford / Sterling, 1992 1990, Cargo CF 600-800, SD508, 6.6L/7.8L, OEM# F1HZ-19703E

Ford / Sterling, 1991 1990, L,LN,LT Series, w/Sanden SD508 w/FNH (before 12/90) (w/o clutch), OEM# F1HZ-19703E

Specifications

Manufacturer #: 95943

Application: Ford/Sterling Trucks

Description: FORD SANDEN SD508 COMP W/O O

Clutch Diameter: w/o CLUTCH

Belt Type: w/o CLUTCH

No. Comp. Cylinders: 5 cyl

Comp. Displacement (ci): 8.4 cu.in.

Factory Oil Charge: 310cc Oil

Fitting Port Position: Vertical

Fitting Style: Male Insert O-Ring #8 & #10

Head Type: FQ

Wire Type: None

Replacement Clutch Assy.: w/o CLUTCH

Replacement Head Assy: NSS

Model: SD508

Mounting Type: Ear 8 Long

Oil Type: Mineral

Product Name: Compressor

Refrigerant Type: R12

Rotation: CW/CCW

O-Ring #1: 16-4208

O-Ring #2: 16-4210

Shaft Type: SD5 Keyed Shaft

All Our Parts are Brand New and covered by the Original Equipment Manufacturer's Warranty

We carry a full line of Sanden compressors, Seltec/Valeo compressors along with all other brands for Freightliner, Ford, Kenworth, Mack, Peterbilt, Volvo/GM Trucks, Caterpillar, Bus, RV and Van AC parts.

INTERCHANGE: 5995NC N83-304842 E9HT-19D629CB F0HZ-19703B F0HZ-19703D F1HZ-19703E N83304842 E9HT19D629CB F0HZ19703B F0HZ19703D F1HZ19703E 95943
