Sanden Compressor - Genuine - Manufacturer #: 4549 - Freightliner Trucks
Make: Sanden
Manufacturer #: 4549
Application: Freightliner Trucks
Description: Sanden Super HD AC Compressor
Additional Description: Super HD style
Volts: 12V
Other OE Sanden #: 4549
Clutch Diameter: 125mm
No. of Grooves: 6 groove
Belt Type: Serpentine
No. Comp. Cylinders: 7 cyl
Comp. Displacement (ci): 9.5 cu.in.
Factory Oil Charge: 300cc Oil
Fitting Port Position: Horizontal
Fitting Style: Pad w/Slimline connections
Head Type: GH
Wire Type: 2 Wire Female Packard #15300002
Replacement Clutch Assy.: 02-0606S
Replacement Head Assy: 03-6551
Model: SD7H15-Super HD
Mounting Type: Direct Short
OEM Number: ABPN83-304573S
Oil Type: PAG100
Product Name: Compressor
Refrigerant Type: R134a
Rotation: CW
Shaft Type: Long Key Shaft
Diode Protection: Diode/Thermal Fuse
Truck Air Oring 1: 16-4272
Truck Air Seal 1: 16-4272
Sanden Compressor 4549 4076 for Freightliner
All w/6 gr 125mm (C10/12 3406e,ISM, ISX), heavy duty version w/OE # 4549
INTERCHANGE: AIRSOURCE 5334S; ALLIANCE N83-304573S; SANDEN 4076
All Our Parts are Brand New and covered by the Original Equipment Manufacturer's Warranty
We carry a full line of Sanden compressors, Seltec/Valeo compressors along with all other brands for Freightliner, Ford, Kenworth, Mack, Peterbilt, Volvo/GM Trucks, Caterpillar, Bus, RV and Van AC parts.
