QCC AC Compressor - Professional Grade OEM #: 3611894-C92 - Navistar Trucks
OEM Number: 3611894-C92
Make: QCC Compressor
Manufacturer #: QP7H15-4347
Application: Navistar Trucks
Description: QCC Compressor
Additional Description: QCC Compressor
Volts: 12v
Clutch Diameter: 119mm
No. of Grooves: 10 groove
Belt Type: Serpentine
No. Comp. Cylinders: 7 cyl
Comp. Displacement (ci): 9.5 cu.in.
Factory Oil Charge: 300cc Oil
Fitting Port Position: Top
Fitting Style: Pad
Head Type: GWA
Wire Type: 2 Wire
Replacement Clutch Assy.: NSS
Replacement Head Assy: NSS
Model: QP7H15
Oil Type: PAG100
Product Name: A/C Compressor
Rotation: CW
Shaft Type: Keyed shaft
Truck Air Oring 1: 16-4210
Truck Air Seal 1: 16-4210
INTERCHANGE: AIRSOURCE
All Our Parts are Brand New and covered by the Original Equipment Manufacturer's Warranty
We carry a full line of Sanden compressors, Seltec/Valeo compressors along with all other brands for Freightliner, Ford, Kenworth, Mack, Peterbilt, Volvo/GM Trucks, Caterpillar, Bus, RV and Van AC parts.
