Sanden 4024 Kenworth Trucks OEM# 1803-6000
Kenworth, Peterbilt, All, w/8 gr 119mm (24Volt) GQ Head, Dir. Mount, #4024, OEM# 1803-6000
Specifications
Manufacturer #: 4024
Application: Kenworth Trucks
Description: SANDEN SUPRHD COMPR. /PACCAR
Additional Description: Super HD style
Volts: 24V
Clutch Diameter: 119mm
No. of Grooves: 8 groove
Belt Type: Serpentine
No. Comp. Cylinders: 7 cyl
Comp. Displacement (ci): 9.5 cu.in.
Factory Oil Charge: 300cc Oil
Fitting Port Position: Lateral
Fitting Style: O-ring Pad @ 90 deg
Head Type: GQ
Wire Type: 2 Wire AMP #282104-1
Replacement Clutch Assy.: NSS
Replacement Head Assy: 03-6552
Model: SD7H15-Super HD
Mounting Type: Direct Long
OEM Number: 1803-6000
Oil Type: PAG100
Product Name: Compressor
Refrigerant Type: R134a
Rotation: CW
O-Ring #1: 16-4208
O-Ring #2: 16-4210
Shaft Type: Long Key Shaft
Diode Protection: Diode/Thermal Fuse
All Our Parts are Brand New and covered by the Original Equipment Manufacturer's Warranty
We carry a full line of Sanden compressors, Seltec/Valeo compressors along with all other brands for Freightliner, Kenworth, Mack, Peterbilt, Volvo/GM Trucks, Caterpillar, buses, RV's and vans.
INTERCHANGE: 4024
