Sanden 4326 Volvo GM OEM# 20721587 Mack OEM# 206RD52M
Volvo GM, w/8 gr. 180mm Direct Mount, WV Head (4326), OEM# 20721587
Mack, w/8 gr. 180mm Direct Mount, WV Head (4326), OEM# 206RD52M, 206RD53M
Specifications
Manufacturer #: 4326
Application: Mack/Volvo Trucks
Description: SD7H15 SHD COMPRESSOR/MACK
Additional Description: Sealed Super HD Style
Volts: 12V
Clutch Diameter: 180mm
No. of Grooves: 8 groove
Belt Type: Serpentine
No. Comp. Cylinders: 7 cyl
Comp. Displacement (ci): 9.5 cu.in.
Factory Oil Charge: 300cc Oil
Fitting Port Position: Horizontal
Fitting Style: Rear Pad O-ring, Volvo Off-Set Top Left, Suc over Dis
Head Type: WV
Wire Type: 2 Wire Female Packard #15300002
Replacement Clutch Assy.: NSS
Replacement Head Assy: 03-6562
Model: 7H15SPRHD
Mounting Type: Direct Short
OEM Number: 206RD53M, 20721587
Oil Type: PAG100
Product Name: Compressor
Refrigerant Type: R134a
Rotation: CW
O-Ring #1: 16-4270
O-Ring #2: 16-4269
Shaft Type: Long Key Shaft
Diode Protection: w/diode
All Our Parts are Brand New and covered by the Original Equipment Manufacturer's Warranty
We carry a full line of Sanden compressors, Seltec/Valeo compressors along with all other brands for Freightliner, Ford, Kenworth, Mack, Peterbilt, Volvo/GM Trucks, Caterpillar, Bus, RV and Van AC parts.
INTERCHANGE: 5404 206RD52M 4326 20721587
Mack, w/8 gr. 180mm Direct Mount, WV Head (4326), OEM# 206RD52M, 206RD53M
Specifications
Manufacturer #: 4326
Application: Mack/Volvo Trucks
Description: SD7H15 SHD COMPRESSOR/MACK
Additional Description: Sealed Super HD Style
Volts: 12V
Clutch Diameter: 180mm
No. of Grooves: 8 groove
Belt Type: Serpentine
No. Comp. Cylinders: 7 cyl
Comp. Displacement (ci): 9.5 cu.in.
Factory Oil Charge: 300cc Oil
Fitting Port Position: Horizontal
Fitting Style: Rear Pad O-ring, Volvo Off-Set Top Left, Suc over Dis
Head Type: WV
Wire Type: 2 Wire Female Packard #15300002
Replacement Clutch Assy.: NSS
Replacement Head Assy: 03-6562
Model: 7H15SPRHD
Mounting Type: Direct Short
OEM Number: 206RD53M, 20721587
Oil Type: PAG100
Product Name: Compressor
Refrigerant Type: R134a
Rotation: CW
O-Ring #1: 16-4270
O-Ring #2: 16-4269
Shaft Type: Long Key Shaft
Diode Protection: w/diode
All Our Parts are Brand New and covered by the Original Equipment Manufacturer's Warranty
We carry a full line of Sanden compressors, Seltec/Valeo compressors along with all other brands for Freightliner, Ford, Kenworth, Mack, Peterbilt, Volvo/GM Trucks, Caterpillar, Bus, RV and Van AC parts.
INTERCHANGE: 5404 206RD52M 4326 20721587
