Sanden Compressor #: 4581 SD7H15E
Make: Sanden
Manufacturer #: 4581
Application: Mack/Volvo Trucks
Description: Sanden Compressor/VOLVO-MACK
Additional Description: Enhanced Version
Volts: 12V
Clutch Diameter: 119mm
No. of Grooves: 8 groove
Belt Type: Serpentine
No. Comp. Cylinders: 7 cyl
Comp. Displacement (ci): 13 cu.in.
Factory Oil Charge: 300cc Oil
Fitting Port Position: Horizontal
Fitting Style: Rear Pad O-ring, Volvo Off-Set Top Left, Suc over Dis
Head Type: WV
Wire Type: 2 Wire Female Packard #15300002
Replacement Clutch Assy.: NSS
Replacement Head Assy: 03-6562
Model: SD7H15E
Mounting Type: Direct Long
OEM Number: 21462260
Oil Type: PAG100
Product Name: Compressor
Refrigerant Type: R134a
Rotation: CW
Shaft Type: Long Key Shaft
Diode Protection: w/diode
Truck Air Oring 1: 16-4270
Truck Air Oring 2: 16-4269
Truck Air Seal 1: 16-4270
Truck Air Seal 2: 16-4269
INTERCHANGE: Airsource 54581; Sanden 4581, 4103, 4110; Mack 21462260
All Our Parts are Brand New and covered by the Original Equipment Manufacturer's Warranty
We carry a full line of Sanden compressors, Seltec/Valeo compressors along with all other brands for Freightliner, Ford, Kenworth, Mack, Peterbilt, Volvo/GM Trucks, Caterpillar, Bus, RV and Van AC parts.
