Sanden Compressor # 4705 Kenworth OEM# F69-6002 18-04178
Kenworth, All Models, w/6 gr 119mm 4.6" 2 wire (4705), OEM# F69-6002, F69-6002-212, 18-04178
Peterbilt, w/6 gr 119mm 4.6" 2 wire (4705), OEM# F69-6002, F69-6001-211, 18-04178
Peterbilt, w/8 gr 119mm 3126, 3116 #4705, OEM# 18-04178
Specifications
Manufacturer #: 4705
Application: Peterbilt Trucks
Description: Sanden Compressor
Volts: 12V
Clutch Diameter: 119mm
No. of Grooves: 8 groove
Belt Type: Serpentine
No. Comp. Cylinders: 7 cyl
Comp. Displacement (ci): 9.5 cu.in.
Factory Oil Charge: 300cc Oil
Fitting Port Position: Lateral
Fitting Style: O-ring Pad @ 90 deg
Head Type: GQ
Wire Type: 2 Wire Female Packard #15300002
Replacement Clutch Assy.: 02-0601
Replacement Head Assy: 03-6552
Model: SD7H15HD
Mounting Type: Ear 8 Long
OEM Number: F69-6002
Oil Type: PAG100
Product Name: Compressor
Refrigerant Type: R134a
Rotation: CW
O-Ring #1: 16-4208
O-Ring #2: 16-4210
Shaft Type: Long Key Shaft
Diode Protection: w/diode
All Our Parts are Brand New and covered by the Original Equipment Manufacturer's Warranty
We carry a full line of Sanden compressors, Seltec/Valeo compressors along with all other brands for Freightliner, Ford, Kenworth, Mack, Peterbilt, Volvo/GM Trucks, Caterpillar, Bus, RV and Van AC parts.
INTERCHANGE: 5361 18-04175 18-04178 4696-9910 F69-6001-211 F69-6002 F69-6002-212 4705 1804175 1804178 46969910 F696001211 F696002 F696002212
