Sanden Compressor # 4739 Kenworth OEM# 18-04291 Peterbilt
Kenworth, All Models, w/8 gr 119mm 3126, 3116 #4739, OEM# 18-04291
Peterbilt, All Models, w/8 gr 119mm 3126, 3116 #4739, OEM# 18-04291, F69-6002-214
Specifications
Manufacturer #: 4739
Application: Peterbilt Trucks
Description: Sanden Compressor
Volts: 12V
Clutch Diameter: 119mm
No. of Grooves: 8 groove
Belt Type: Serpentine
No. Comp. Cylinders: 7 cyl
Comp. Displacement (ci): 9.5 cu.in.
Factory Oil Charge: 300cc Oil
Fitting Port Position: Horizontal
Fitting Style: Male Insert O-Ring #8 & #10
Head Type: KG
Wire Type: 2 Wire Female Packard #15300002
Replacement Clutch Assy.: 02-0609 see note
Replacement Head Assy: 03-6540G
Model: SD7H15HD
Mounting Type: Ear 8 Long
OEM Number: 18-04291
Oil Type: PAG100
Product Name: Compressor
Refrigerant Type: R134a
Rotation: CW
O-Ring #1: 16-4208
O-Ring #2: 16-4210
Shaft Type: Long Key Shaft
Diode Protection: w/diode
All Our Parts are Brand New and covered by the Original Equipment Manufacturer's Warranty
We carry a full line of Sanden compressors, Seltec/Valeo compressors along with all other brands for Freightliner, Ford, Kenworth, Mack, Peterbilt, Volvo/GM Trucks, Caterpillar, Bus, RV and Van AC parts.
INTERCHANGE: 5367 N83-304394 N83304394 1401374 18-04291 F69-6002-214 75R-81562 RD5-11334-0 1804291 F696002214 75R81562 RD5113340 4739
