Sanden Style Aftermarket Compressor Peterbilt
Sanden Style Aftermarket Compressor Peterbilt
Sanden Style Aftermarket Compressor Peterbilt
Item#: 03-1403G
Availability: Usually ships the same business day
$194.67

Product Description
Application: Peterbilt Trucks

Volts: 12V

Clutch Diameter: 125mm

No. of Grooves: 2 groove

Belt Type: Two 1/2'' Belts

No. Comp. Cylinders: 7 cyl

Factory Oil Charge: 300cc Oil

Fitting Port Position: Vertical

Fitting Style: Male Insert O-Ring #8 & #10

Head Type: JDA

Model: SD7H15HD

Oil Type: PAG100

Product Name: Compressor

Refrigerant Type: R134a

Rotation: CW

Shaft Type: Splined shaft

Diode Protection: w/diode



All Our Parts are Brand New and covered by the Original Equipment Manufacturer's Warranty

INTERCHANGE: AIRSOURCE #5363G, ALLIANCE #N83-304173, CLIMATECH #LE1640 / QP7H15-4713P, FLEETRITE #FLT4713Q, KYSOR #1401434, KENWORTH PETERBILT #18-04088 / F69-6001-233, RED DOT #75R-84312, SANDEN #4433 / 4713

We carry a full line of Sanden compressors, Seltec/Valeo compressors along with all other brands for Freightliner, Ford, Kenworth, Mack, Peterbilt, Volvo/GM Trucks, Caterpillar, Bus, RV and Van AC parts.
