SANDEN 4717 Volvo GM OEM# 8082270
Sanden compressor for Volvo (GM)
w/2 gr. 132mm 5-1/4" C3126, M11 eng. w/WV head, OEM# 4717, 8082270
w/2 gr. 132mm 5-1/4" C3126, M11 eng., OEM# 4777, 4893 20370289, 85104592, 2521475
Specifications
Manufacturer #: 4717
Application: Volvo Trucks
Description: Sanden Compressor
Volts: 12V
Clutch Diameter: 132mm
No. of Grooves: 2 groove
Belt Type: Two 1/2'' Belts
No. Comp. Cylinders: 7 cyl
Comp. Displacement (ci): 9.5 cu.in.
Factory Oil Charge: 300cc Oil
Fitting Port Position: Horizontal
Fitting Style: Rear Pad O-ring, Volvo Off-Set Top Left, Suc over Dis
Head Type: WV
Wire Type: 2 Wire Female Packard #15300002
Replacement Clutch Assy.: 02-1604
Replacement Head Assy: 03-6562
Model: SD7H15
Mounting Type: Ear 8 Long
OEM Number: 20370289
Oil Type: PAG100
Product Name: Compressor
Refrigerant Type: R134a
Rotation: CW
O-Ring #1: 16-4270
O-Ring #2: 16-4269
Shaft Type: Long Key Shaft
Diode Protection: w/diode
All Our Parts are Brand New and covered by the Original Equipment Manufacturer's Warranty
We carry a full line of Sanden compressors, Seltec/Valeo compressors along with all other brands for Freightliner, Ford, Kenworth, Mack, Peterbilt, Volvo/GM Trucks, Caterpillar, bus, RV and van AC parts.
INTERCHANGE: N83-304442 N83-304634 N83-304639 N83304442 N83304634 N83304639 ZGG705128 2521475 1406001 75R-8722 E80131775R8722 E801317 U4717
