Sanden Style A/C Compressor Aftermarket - Volvo
OEM Number: 8080060, 85104468
Make: Sanden Style
Manufacturer #: 4694
Application: Volvo Trucks
Description: Sanden Style Compressor
Volts: 12V
Clutch Diameter: 132mm
No. of Grooves: 2 groove
Belt Type: Two 1/2'' Belts
No. Comp. Cylinders: 7 cyl
Comp. Displacement (ci): 9.5 cu.in.
Factory Oil Charge: 300cc Oil
Fitting Port Position: Vertical
Fitting Style: Male Insert O-Ring #8 & #10
Head Type: JD
Wire Type: 2 Wire Female Packard #15300002
Replacement Clutch Assy.: 02-1604
Replacement Head Assy: 03-6533
Model: SD7H15HD
Oil Type: PAG100
Product Name: Compressor
Refrigerant Type: R134a
Rotation: CW
Shaft Type: Long Key Shaft
Diode Protection: w/diode
Truck Air Oring 1: 16-4208
Truck Air Oring 2: 16-4210
Truck Air Seal 1: 16-4208
Truck Air Seal 2: 16-4210
All Our Parts are Brand New and covered by the Original Equipment Manufacturer's Warranty
INTERCHANGE: AIRSOURCE #5380G, ALLIANCE #N83-304193, FLEETRITE #FLT4896Q / ZGG19370, KYSOR #1401343, RED DOT #75R-84362, SANDEN #4694 / 4896, VOLVO #8080060 / 85104468
We carry a full line of Sanden compressors, Seltec/Valeo compressors along with all other brands for Freightliner, Ford, Kenworth, Mack, Peterbilt, Volvo/GM Trucks, Caterpillar, Bus, RV and Van AC parts.
