Sanden 4071 Western Star OEM# SKI4071
Specifications
Manufacturer #: 4071
Application: Western Star Trucks
Description: SANDEN COMPRESSOR/WEST.STAR
Additional Description: Super HD style
Volts: 12V
Clutch Diameter: 125mm
No. of Grooves: 6 groove
Belt Type: Serpentine
No. Comp. Cylinders: 7 cyl
Comp. Displacement (ci): 9.5 cu.in.
Factory Oil Charge: 300cc Oil
Fitting Port Position: Top
Fitting Style: Ford O-ring Pad
Head Type: WH
Wire Type: 2 Wire Female Packard #15300002
Replacement Clutch Assy.: 02-0606S
Replacement Head Assy: NSS
Model: SD7H15-Super HD
Mounting Type: Direct Short
OEM Number: SKI4071S
Oil Type: PAG100
Product Name: Compressor
Refrigerant Type: R134a
Rotation: CW
O-Ring #1: 16-4208
O-Ring #2: 16-4210
Shaft Type: Long Key Shaft
Diode Protection: Diode/Thermal Fuse
All Our Parts are Brand New and covered by the Original Equipment Manufacturer's Warranty
We carry a full line of Sanden compressors, Seltec/Valeo compressors along with all other brands for Freightliner, Ford, Kenworth, Mack, Peterbilt, Volvo/GM Trucks, Caterpillar, Bus, RV and Van AC parts.
INTERCHANGE: 54071 4071 SKI4071
