Chev/GM A/C Compressor OEM Grade
Chev/GM A/C Compressor OEM Grade
Chev/GM A/C Compressor OEM Grade
Item#: 03-1841-OE
Availability: Usually ships the same business day
$433.61

Product Description
OEM Number: 1131346

Make: Delphi GM

Application: Chev/GMC Trucks

Description: GM Harrison R-4 Comp

Volts: 12V

Clutch Diameter: 109.9mm

No. of Grooves: 6 groove

Belt Type: Serpentine

No. Comp. Cylinders: 10 cyl

Comp. Displacement (ci): 10.0 cu.in.

Factory Oil Charge: Check label instructions

Fitting Port Position: Rear

Fitting Style: GM Sealing Washer Pad

Head Type: Plain head

Wire Type: Plug

Replacement Clutch Assy.: NSS

Model: R4

Oil Type: PAG150

Product Name: Compressor

Refrigerant Type: R134a

Shaft Type: Keyed shaft



All Our Parts are Brand New and covered by the Original Equipment Manufacturer's Warranty

INTERCHANGE: AIRSOURCE #5889-OE, FLEETRITE #ZGG705086 / ZGG705089 / ZGG705109 / ZGG705115 / Chevrolet GMC #1131346 / 2724353 / 2724354

We carry a full line of Sanden compressors, Seltec/Valeo compressors along with all other brands for Freightliner, Ford, Kenworth, Mack, Peterbilt, Volvo/GM Trucks, Caterpillar, Bus, RV and Van AC parts.
