Chev/GM A/C Compressor OEM Grade #1134343

Chev/GM A/C Compressor OEM Grade #1134343

Item# 03-1846-OE
Availability: Usually ships the same business day.

OEM Number: 1134343

Make: Delphi GM

Application: Chev/GMC Trucks

Description: GM Harrison R-4 Comp

Volts: 12V

Clutch Diameter: 109.9mm

No. of Grooves: 6 groove

Belt Type: Serpentine

No. Comp. Cylinders: 10 cyl

Comp. Displacement (ci): 10.0

Factory Oil Charge: Check label instructions

Fitting Port Position: Rear

Fitting Style: GM Sealing Washer Pad

Head Type: Pressure switch port

Wire Type: Plug

Replacement Clutch Assy.: NSS

Model: R4

Oil Type: PAG150

Product Name: Compressor

Refrigerant Type: R134a

Shaft Type: Keyed shaft

All Our Parts are Brand New and covered by the Original Equipment Manufacturer's Warranty

INTERCHANGE: AIRSOURCE #5888-OE, DELPHI #CS0002, FLEETRITE #ZGG705085 / ZGG705088 / ZGG705090 / ZGG705114 / ZGG705117 / ZGG705118, CHEVROLET GMC (GM) #1131852 / 1131880 / 1131921 / 1134302 / 1134327 / 1134328 / 1134330 / 1134343

We carry a full line of Sanden compressors, Seltec/Valeo compressors along with all other brands for Freightliner, Ford, Kenworth, Mack, Peterbilt, Volvo/GM Trucks, Caterpillar, Bus, RV and Van AC parts.
