T/CCI (York Style) Compressor w/ 6 grv Clutch ES210L-25336C
Freightliner, 2002 2000, All w/6 grv clutch, w/Slim-line, OEM# ES210L-25336C
Specifications
Manufacturer: T/CCI (York Style)
Manufacturer #: ES210L-25336C
Application: Freightliner Trucks
Description: CCI Comp w/ 6 grv Clutch
Volts: 12V
Clutch Diameter: 5-7/8''
No. of Grooves: 6 groove
Belt Type: Serpentine
No. Comp. Cylinders: 2 cyl
Comp. Displacement (ci): 10 c.i.
Factory Oil Charge: 14 oz oil
Fitting Port Position: LH SUCTION
Fitting Style: Slimline connections
A-B Distance: 1-5/8''
Head Type: SLIM LINE
Wire Type: 2 WIRE-METRIPAK
Replacement Clutch Assy.: 02-3416
Replacement Head Assy: NSS
Model: ES210L
Oil Type: PAG100
Product Name: Compressor
Refrigerant Type: R12/R134a
Rotation: CW/CCW
O-Ring #1: 16-4265
O-Ring #2: 16-4265
Shaft Type: Keyed shaft
Diode Protection: w/diode
All Our Parts are Brand New and covered by the Original Equipment Manufacturer's Warranty
We carry a full line of Sanden compressors, Seltec/Valeo compressors along with all other brands for Freightliner, Ford, Kenworth, Mack, Peterbilt, Volvo/GM Trucks, Caterpillar, Bus, RV and Van AC parts.
INTERCHANGE: ES210L25336C
