Seltec/Valeo Compressor OEM #: 10356228 - Farm & Off Road Applications
OEM Number: 10356228, 10056228, 488-46228
Make: Seltec - Valeo
Manufacturer: Valeo
Application: Farm & Off Road Applications
Description: A/C Compressor, R134A
Volts: 24V
Clutch Diameter: 158mm
No. of Grooves: 1 groove
Belt Type: Variable groove
No. Comp. Cylinders: 6 cyl
Comp. Displacement (ci): 9.7 cu.in.
Factory Oil Charge: 180cc Oil
Fitting Port Position: Horizontal
Fitting Style: Universal O-ring Pad
Head Type: G - Univ Pad type
Wire Type: 1 Wire bullet
Replacement Clutch Assy.: 02-3053
Replacement Head Assy: NSS
Model: TM16HD/HS
Mounting Type: Ear mount
Oil Type: PAG46
Product Name: Compressor
Refrigerant Type: R134a
Rotation: CW/CCW
Shaft Type: Splined shaft
Diode Protection: None
Truck Air Oring 1: 16-4144
Truck Air Seal 1: 16-4144
INTERCHANGE: AIRSOURCE 5804; ALLIANCE N83-304789; ICE 2521477; QUE PRODUCTS QP16-1192, QP16-1194; RED DOT 75R-8644, 75R-8644Q; SANDEN 8037; SELTEC / VALEO 10055228, 10055361, 10056073, 10056228, 10056357, 435-55228, 435-55361, 435-56073, 435-56228, 435-56357, 488-43073, 488-45073, 488-45228, 488-45361, 488-46061, 488-46073, 488-46228, 488-46357; THERMOKING 102-586
All Our Parts are Brand New and covered by the Original Equipment Manufacturer's Warranty
We carry a full line of Sanden compressors, Seltec/Valeo compressors along with all other brands for Freightliner, Ford, Kenworth, Mack, Peterbilt, Volvo/GM Trucks, Caterpillar, Bus, RV and Van AC parts.
