T/CCI (York Style) Manufacturer #: ET210L-25237C
Specifications
Manufacturer: T/CCI (York Style)
Manufacturer #: ET210L-25237C
Application: Multi Fit Applications
Description: QCC STYLE ET210L-25237C COMP
Volts: 12V
Clutch Diameter: 6''
No. of Grooves: 2 groove
Belt Type: Two 1/2'' Belts
No. Comp. Cylinders: 2 cyl
Comp. Displacement (ci): 10 c.i.
Factory Oil Charge: 14 oz oil
Fitting Port Position: LH SUCTION
Fitting Style: Tube-O 1 x 14
A-B Distance: 1-3/4'' X 2-1/4''
Head Type: TUBE-O
Wire Type: 2 Wire Metripack
Replacement Clutch Assy.: 02-3412
Model: ET210L
Mount Type: Clutch has keyed shaft
Oil Type: PAG100
Product Name: Compressor
Refrigerant Type: R12/R134a
Rotation: CW/CCW
O-Ring #1: 16-4210
O-Ring #2: 16-4210
Shaft Type: Keyed shaft
Diode Protection: w/diode
All Our Parts are Brand New and covered by the Original Equipment Manufacturer's Warranty
We carry a full line of Sanden compressors, Seltec/Valeo compressors along with all other brands for Freightliner, Ford, Kenworth, Mack, Peterbilt, Volvo/GM Trucks, Caterpillar, Bus, RV and Van AC parts.
INTERCHANGE: 5218
