Sanden Style A/C Compressor T/CCI
Make: Sanden
Manufacturer #: 4318
Application: T/CCI Compressor Applications
Description: SANDEN T/CCI COMPRESSOR 2GR
Volts: 12V
Clutch Diameter: 132mm
No. of Grooves: 2 groove
Belt Type: Two 1/2'' Belts
No. Comp. Cylinders: 7 cyl
Comp. Displacement (ci): 9.5 cu.in.
Factory Oil Charge: None-Check label instructions
Fitting Port Position: Top
Fitting Style: Pad
Head Type: UK
Wire Type: 2 Wire Female Packard #15300002 W/ Jumper #4315-0400
Replacement Clutch Assy.: NSS
Replacement Head Assy: 03-6548
Model: SD7H15HD
Oil Type: PAG100
Product Name: Compressor
Refrigerant Type: R134a
Rotation: CW
Shaft Type: Long Key Shaft
Diode Protection: w/diode
Truck Air Oring 1: 16-4208
Truck Air Oring 2: 16-4210
Truck Air Seal 1: 16-4232
Truck Air Seal 2: 16-4243
All Our Parts are Brand New and covered by the Original Equipment Manufacturer's Warranty
INTERCHANGE: AIRSOURCE #5299G, KYSOR #1410060, SANDEN #4318
We carry a full line of Sanden compressors, Seltec/Valeo compressors along with all other brands for Freightliner, Ford, Kenworth, Mack, Peterbilt, Volvo/GM Trucks, Caterpillar, Bus, RV and Van AC parts.
