Sanden Compressor # 4508
Specifications
Manufacturer #: 4508
Application: Multi Fit Applications
Description: A/C Compressor, R134a
Volts: 12V
Clutch Diameter: 125mm
No. of Grooves: 10 groove
Belt Type: Serpentine
No. Comp. Cylinders: 5 cyl
Comp. Displacement (ci): 8.4 cu.in.
Factory Oil Charge: 135cc Oil
Fitting Port Position: Vertical
Fitting Style: Male Insert O-Ring #8 & #10
Head Type: FL
Wire Type: 1 Wire Male Bullet
Replacement Clutch Assy.: 02-3476
Replacement Head Assy: 03-6543
Model: SD5H14
Mounting Type: Ear 8 Long
Oil Type: PAG100
Product Name: Compressor
Refrigerant Type: R134a
Rotation: CW/CCW
O-Ring #1: 16-4208
O-Ring #2: 16-4210
Shaft Type: SD5 Keyed Shaft
Diode Protection: None
All Our Parts are Brand New and covered by the Original Equipment Manufacturer's Warranty
We carry a full line of Sanden compressors, Seltec/Valeo compressors along with all other brands for Freightliner, Ford, Kenworth, Mack, Peterbilt, Volvo/GM Trucks, Caterpillar, Bus, RV and Van AC parts.
INTERCHANGE: 5712 N83-304682 N83304682 ZGG19278 1401101 75R-83152 75R83152 4508 6656
