Sanden Style A/C Compressor  - Aftermarket - Autocar
Zoom

Sanden Style A/C Compressor - Aftermarket - Autocar

Item# 03-3501G
$334.33
Availability: Usually ships the same business day.

Make: Sanden Style

Application: Autocar Applications

Additional Description: Super HD style

Volts: 12V

Clutch Diameter: 119mm

No. of Grooves: 8 groove

Belt Type: Serpentine

No. Comp. Cylinders: 7 cyl

Comp. Displacement (ci): 9.5 cu.in.

Factory Oil Charge: 250cc Oil

Fitting Port Position: Horizontal

Fitting Style: Rear Universal O-ring FLX-7 Pad

Head Type: GV

Wire Type: 1 Wire Male Packard #12015791 W/ Diode

Replacement Clutch Assy.: 02-0601S

Replacement Head Assy: 03-6554

Model: SD7H15HD

Oil Type: PAG100

Product Name: Compressor

Refrigerant Type: R134a

Rotation: CW

Shaft Type: Long Key Shaft

Diode Protection: w/diode

Truck Air Oring 1: 16-4224

Truck Air Seal 1: 16-4224



All Our Parts are Brand New and covered by the Original Equipment Manufacturer's Warranty

INTERCHANGE: AIRSOURCE #54029G, SANDEN #4028

We carry a full line of Sanden compressors, Seltec/Valeo compressors along with all other brands for Freightliner, Ford, Kenworth, Mack, Peterbilt, Volvo/GM Trucks, Caterpillar, Bus, RV and Van AC parts.
