Sanden Style A/C Compressor  - Aftermarket - Farm & Offroad

Sanden Style A/C Compressor - Aftermarket - Farm & Offroad

Item# 03-3511G
Availability: Usually ships the same business day.

Application: Farm & Off Road Applications

Description: SD7H15SHD W/133MM 8GR 12V

Additional Description: Sealed HD style

Volts: 12V

Clutch Diameter: 133mm

No. of Grooves: 8 groove

Belt Type: Serpentine

No. Comp. Cylinders: 7 cyl

Comp. Displacement (ci): 9.5

Factory Oil Charge: 270cc Oil

Fitting Port Position: Vertical

Fitting Style: Male Insert O-Ring #8 & #10

Head Type: JD

Wire Type: 2 Wire Male Packard #12015792

Replacement Clutch Assy.: 02-3472

Replacement Head Assy: 03-6533

Model: SD7H15-SHD

Oil Type: PAG100

Product Name: Compressor

Refrigerant Type: R134a

Rotation: CW

Shaft Type: Long Key Shaft

Diode Protection: None

Truck Air Oring 1: 16-4208

Truck Air Oring 2: 16-4210

Truck Air Seal 1: 16-4208

Truck Air Seal 2: 16-4210

All Our Parts are Brand New and covered by the Original Equipment Manufacturer's Warranty


We carry a full line of Sanden compressors, Seltec/Valeo compressors along with all other brands for Freightliner, Ford, Kenworth, Mack, Peterbilt, Volvo/GM Trucks, Caterpillar, Bus, RV and Van AC parts.
