Sanden Aftermarket Grade 7351 - Farm & Off Road Applications
OEM Number: TDKR151320S, TDKR151340S
Make: Sanden
Manufacturer #: 7351
Application: Farm & Off Road Applications
Description: SD7H13 W/1-B GR 24V WM HEAD
Volts: 24V
Other OE Sanden #: 7351
Clutch Diameter: 146mm
No. of Grooves: 1 groove
Belt Type: 5/8'' Belt
No. Comp. Cylinders: 7 cyl
Comp. Displacement (ci): 7.9 cu.in.
Factory Oil Charge: 135cc Oil
Fitting Port Position: Horizontal
Fitting Style: Pad
Head Type: WM
Wire Type: 1 Wire Male Bullet
Replacement Clutch Assy.: NSS
Replacement Head Assy: NSS
Model: SD7H13HD
Mounting Type: SD7H13
Oil Type: PAG100
Product Name: Compressor
Refrigerant Type: R134a
Rotation: CW
Diode Protection: None
Truck Air Oring 1: ,
Truck Air Oring 2: ,
Truck Air Seal 1: ,
Truck Air Seal 2: ,
INTERCHANGE: AIRSOURCE 57351G; SANDEN 7351, 7359, 8925
All Our Parts are Brand New and covered by the Original Equipment Manufacturer's Warranty
We carry a full line of Sanden compressors, Seltec/Valeo compressors along with all other brands for Freightliner, Ford, Kenworth, Mack, Peterbilt, Volvo/GM Trucks, Caterpillar, Bus, RV and Van AC parts.
