Seltec Compressor OEM# xxx-25057
Shuttle Buses & Vans, School Buses, All w/Zexel/Diesel-Kiki, DKS15, w/VG clutch (24 volt)
Specifications
Manufacturer #: 488-25057
Application: Farm & Off Road Applications
Description: A/C Compressor, R12
Volts: 24V
Clutch Diameter: 158mm
No. of Grooves: 1 groove
Belt Type: Variable groove
No. Comp. Cylinders: 6 cyl
Comp. Displacement (ci): 9.0 cu.in.
Factory Oil Charge: 150cc Oil
Fitting Port Position: Vertical
Fitting Style: Male Insert O-Ring #8 & #10
Head Type: B
Wire Type: 1 Wire bullet
Replacement Clutch Assy.: 02-3053
Replacement Head Assy: 03-6507A
Model: TM15
Mounting Type: Ear mount
Oil Type: Mineral
Product Name: Compressor
Refrigerant Type: R12
Rotation: CW/CCW
O-Ring #1: 16-4208
O-Ring #2: 16-4210
Shaft Type: Splined shaft
Diode Protection: None
All Our Parts are Brand New and covered by the Original Equipment Manufacturer's Warranty
We carry a full line of Sanden compressors, Seltec/Valeo compressors along with all other brands for Freightliner, Ford, Kenworth, Mack, Peterbilt, Volvo/GM Trucks, Caterpillar, Bus, RV and Van AC parts.
INTERCHANGE: 5824 ZGG705167 1403009 488-22057 488-23057 488-25057 48822057 48823057 48825057
