Sanden Compressor - Genuine OEM Grade - Manufacturer #: 4592
Make: Sanden
Manufacturer #: 4592
Application: Farm & Off Road Applications
Description: Sanden Compressor/KOMATSU
Volts: 24V
Clutch Diameter: 119mm
No. of Grooves: 8 groove
Belt Type: Serpentine
No. Comp. Cylinders: 7 cyl
Comp. Displacement (ci): 9.5 cu.in.
Factory Oil Charge: 300cc Oil
Fitting Port Position: Horizontal
Fitting Style: O-Ring #8 & #10
Head Type: 4545
Wire Type: 2 Wire Deutsch #DT06-2S
Replacement Clutch Assy.: NSS
Replacement Head Assy: NSS
Model: SD7H15HD
Mounting Type: Direct Long
Oil Type: PAG100
Product Name: Compressor
Refrigerant Type: R134a
Rotation: CW
Shaft Type: Long Key Shaft
Truck Air Oring 1: ,
Truck Air Oring 2: ,
Truck Air Seal 1: ,
Truck Air Seal 2: ,
INTERCHANGE: AIRSOURCE 54592
All Our Parts are Brand New and covered by the Original Equipment Manufacturer's Warranty
We carry a full line of Sanden compressors, Seltec/Valeo compressors along with all other brands for Freightliner, Ford, Kenworth, Mack, Peterbilt, Volvo/GM Trucks, Caterpillar, Bus, RV and Van AC parts.
