SANDEN 8148 Off Road OEM# N83-304219
Specifications
Manufacturer #: 8148
Application: Farm & Off Road Applications
Description: SD7H15 COMP W/4GR 12V CLUTCH
Volts: 12V
Clutch Diameter: 112mm
No. of Grooves: 4 groove
Belt Type: Serpentine
No. Comp. Cylinders: 7 cyl
Comp. Displacement (ci): 9.5 cu.in.
Factory Oil Charge: 200cc Oil
Fitting Port Position: Horizontal
Fitting Style: Rear Pad O-ring, Volvo Off-Set Top Left, Suc over Dis
Head Type: WV
Wire Type: 2 Wire Female AMP #282104-1
Replacement Clutch Assy.: NSS
Replacement Head Assy: 03-6562
Model: SD7H15-SHD
Mounting Type: Direct Short
OEM Number: 878029120
Oil Type: PAG100
Product Name: Compressor
Refrigerant Type: R134a
Rotation: CW
O-Ring #1: 16-4270
O-Ring #2: 16-4269
Shaft Type: Long Key Shaft
Diode Protection: None
All Our Parts are Brand New and covered by the Original Equipment Manufacturer's Warranty
We carry a full line of Sanden compressors, Seltec/Valeo compressors along with all other brands for Freightliner, Ford, Kenworth, Mack, Peterbilt, Volvo/GM Trucks, Caterpillar, bus, RV and van AC parts.
INTERCHANGE: 58148 8148 N83-304219 N83304219 878029120 488-22019 488-22058 488-23019 488-23058 488-25019 488-25319 48822019 48822058 48823019 48823058 48825019 48825319
