Seltec Compressor OEM# 488-45021
All Shuttle Buses & Vans, School Buses, w/Zexel/TAMA, TM15, 12 volt (w/2 gr. clutch), (#488-45021), OEM# 501-267A
Specifications
Manufacturer #: 488-45021
Application: Multi Fit Applications
Description: A/C Compressor, R134a
Volts: 12V
Clutch Diameter: 132mm
No. of Grooves: 2 groove
Belt Type: Two 1/2'' Belts
No. Comp. Cylinders: 6 cyl
Comp. Displacement (ci): 9.0 cu.in.
Factory Oil Charge: 150cc Oil
Fitting Port Position: Vertical
Fitting Style: Male Insert O-Ring #8 & #10
Head Type: B
Wire Type: 1 Wire bullet
Replacement Clutch Assy.: 02-3034
Replacement Head Assy: 03-6507A
Model: TM15
Mounting Type: Ear mount
Oil Type: PAG46
Product Name: Compressor
Refrigerant Type: R134a
Rotation: CW/CCW
O-Ring #1: 16-4208
O-Ring #2: 16-4210
Shaft Type: Splined shaft
Diode Protection: None
All Our Parts are Brand New and covered by the Original Equipment Manufacturer's Warranty
We carry a full line of Sanden compressors, Seltec/Valeo compressors along with all other brands for Freightliner, Ford, Kenworth, Mack, Peterbilt, Volvo/GM Trucks, Caterpillar, Bus, RV and Van AC parts.
INTERCHANGE: 5722 N83-304139 N83-304159 N83304139 N83304159 525955 501-267A 501267A ZGG705029 ZGG705036 2521157 1403104 10055021 435-55009 435-55021 435-55071 488-43021 488-45009 488-45021 488-45071 43555009 43555021 43555071 48843021 48845009 48845021 48845071 512084 85100543
