Seltec Compressor 10046510 OEM# 488-46510
Farm & Off-Road ALL EQUIPMENT CLASS VEHICLES, SELTEC / VALEO, TM31, 2 Gr, 152mm dia. 1/2" belt width, 24v, OEM# 488-46510
SHUTTLE BUSES & VANS, Zexel/TAMA-ICE TM 31HD, 24 volt w/2 gr. (2A) Clutch OEM# 488-46510
Manufacturer: Aftermarket Valeo
Manufacturer #: 10046510
Application: Bus Applications
Description: Seltec TM31 comp. w/2Agr 24v
Volts: 24V
Clutch Diameter: 140mm
No. of Grooves: 2 groove
Belt Type: Two 1/2'' Belts
No. Comp. Cylinders: 10 cyl
Comp. Displacement (ci): 15.6 cu.in.
Factory Oil Charge: 500cc Oil
Fitting Port Position: Top
Fitting Style: Male Insert O-Ring #10 & #12
Head Type: TM31
Wire Type: 1 Wire bullet
Replacement Clutch Assy.: 02-3434
Replacement Head Assy: NSS
Model: TM31
Mounting Type: Direct mount
Oil Type: PAG46
Product Name: Compressor
Refrigerant Type: R134a
Rotation: CW
O-Ring #1: 16-4208
O-Ring #2: 16-4210
Shaft Type: Splined shaft
Site_Glass Location: Repl. PNO 50031 (set 2)
Diode Protection: None
All Our Parts are Brand New and covered by the Original Equipment Manufacturer's Warranty
We carry a full line of Sanden compressors, Seltec/Valeo compressors along with all other brands for Freightliner, Ford, Kenworth, Mack, Peterbilt, Volvo/GM Trucks, Caterpillar, Bus, RV and Van AC parts.
INTERCHANGE: 5897 17-31245-00 173124500 2521210 10046510 488-46510 48846510
