Seltec/Valeo Compressor Bus Applications OEM #: 10368510, 10046510
Make: Seltec - Valeo
Manufacturer: Valeo
Application: Bus Applications
Description: Seltec TM31 comp. w/2Agr 24v
Volts: 24V
Clutch Diameter: 140mm
No. of Grooves: 2 groove
Belt Type: Two 1/2'' Belts
No. Comp. Cylinders: 10 cyl
Comp. Displacement (ci): 15.6 cu.in.
Factory Oil Charge: 500cc Oil
Fitting Port Position: Top
Fitting Style: Male Insert O-Ring #10 & #12
Head Type: TM31
Wire Type: 1 Wire bullet
Replacement Clutch Assy.: 02-3434
Replacement Head Assy: NSS
Model: TM31
Mounting Type: Direct mount
OEM Number: 10368510, 10046510
Oil Type: PAG46
Product Name: Compressor
Refrigerant Type: R134a
Rotation: CW
Shaft Type: Splined shaft
Site_Glass Location: Repl. PNO 50031 (set 2)
Notes: Effective August 2017 Valeo TM31 compressors will be supplied with aluminum fittings.
Diode Protection: None
Truck Air Oring 1: 16-4208
Truck Air Oring 2: 16-4210
Truck Air Seal 1: 16-4208
Truck Air Seal 2: 16-4210
INTERCHANGE: AIRSOURCE 5897V
All Our Parts are Brand New and covered by the Original Equipment Manufacturer's Warranty
We carry a full line of Sanden compressors, Seltec/Valeo compressors along with all other brands for Freightliner, Ford, Kenworth, Mack, Peterbilt, Volvo/GM Trucks, Caterpillar, Bus, RV and Van AC parts.
