Seltec Compressor OEM# 488-46048
Specifications
Manufacturer #: 488-46048
Application: Farm & Off Road Applications
Description: SELTEC TM16 W/24V 2GR 152mm
Additional Description: Sealed HD style
Volts: 24V
Clutch Diameter: 152mm
No. of Grooves: 2 groove
Belt Type: Two 1/2'' Belts
No. Comp. Cylinders: 6 cyl
Comp. Displacement (ci): 9.7 cu.in.
Factory Oil Charge: 180cc Oil
Fitting Port Position: Horizontal
Fitting Style: Pad w/C-style #8-#10 O-ring manifold
Head Type: C
Wire Type: 1 Wire bullet
Replacement Clutch Assy.: NSS
Replacement Head Assy: 03-6537
Model: TM16HD/HS
Mounting Type: Ear mount
Oil Type: PAG46
Product Name: Compressor
Refrigerant Type: R134a
Rotation: CW/CCW
O-Ring #1: 16-4208
O-Ring #2: 16-4210
Shaft Type: Splined shaft
Diode Protection: None
All Our Parts are Brand New and covered by the Original Equipment Manufacturer's Warranty
We carry a full line of Sanden compressors, Seltec/Valeo compressors along with all other brands for Freightliner, Ford, Kenworth, Mack, Peterbilt, Volvo/GM Trucks, Caterpillar, Bus, RV and Van AC parts.
INTERCHANGE: 10056048 435-56048 488-46048 435-55048 488-45048 43556048 48846048 43555048 48845048
Manufacturer #: 488-46048
Application: Farm & Off Road Applications
Description: SELTEC TM16 W/24V 2GR 152mm
Additional Description: Sealed HD style
Volts: 24V
Clutch Diameter: 152mm
No. of Grooves: 2 groove
Belt Type: Two 1/2'' Belts
No. Comp. Cylinders: 6 cyl
Comp. Displacement (ci): 9.7 cu.in.
Factory Oil Charge: 180cc Oil
Fitting Port Position: Horizontal
Fitting Style: Pad w/C-style #8-#10 O-ring manifold
Head Type: C
Wire Type: 1 Wire bullet
Replacement Clutch Assy.: NSS
Replacement Head Assy: 03-6537
Model: TM16HD/HS
Mounting Type: Ear mount
Oil Type: PAG46
Product Name: Compressor
Refrigerant Type: R134a
Rotation: CW/CCW
O-Ring #1: 16-4208
O-Ring #2: 16-4210
Shaft Type: Splined shaft
Diode Protection: None
All Our Parts are Brand New and covered by the Original Equipment Manufacturer's Warranty
We carry a full line of Sanden compressors, Seltec/Valeo compressors along with all other brands for Freightliner, Ford, Kenworth, Mack, Peterbilt, Volvo/GM Trucks, Caterpillar, Bus, RV and Van AC parts.
INTERCHANGE: 10056048 435-56048 488-46048 435-55048 488-45048 43556048 48846048 43555048 48845048
